I-O | 82 (discontinued)

8x2 USB 2.0 Desktop Recording Studio

I-O | 82
Larger Images

DAW Inspired.

Lexicon I-O Pro Tools 12 Compatible

No artist likes to be told what to do - what tools to use and what tools you can’t use. Lexicon understands your passion and it inspires us to innovate. Brilliantly designed, the I·O Desktop Recording Series is compatible with any DAW, including Pro Tools 10 through 12. Now this innovative hardware design meets the software capability of any creative passion.

Featuring newly designed dbx® 60V high-voltage, ultra-low noise mic preamps on all 8 channels, the I-O|82 is more than equipped to provide professional recordings that keep your music sounding its best. The preamps run on a high-voltage supply to guarantee stability and provide you with a superior recording across a wide dynamic range. Performance driven A/D – D/A converters ensure pristine 24-bit/96kHz audio to capture every subtle detail of your performance.

The I-O|82 can record eight tracks at once and includes 8 combi-jack mic/line inputs with +48V phantom power, 2 TRS balanced line outputs, 2 hi-Z instrument inputs, 2 high power 1/4" headphone outputs, S/PDIF and MIDI I/O. Dedicated knobs and meters offer easy access to input and output levels and locking combi-jacks make sure that a connection is not lost in the middle of a performance.



  • USB 2.0 Desktop Recording Studio
  • 44.1kHz to 96kHz sample rates, 24-bit resolution
  • Pantheon™ II VST/AU reverb plug-in with 6 legendary Lexicon reverbs
  • dbx® high-voltage, ultra-low noise microphone preamps
  • 8 analog combi-jacks for mic/line inputs
  • Zero-latency monitoring
  • Streamlined monitor form factor
  • 2 side panel ¼" instrument input
  • 2 analog ¼" TRS outputs
  • Separate source gain control per channel
  • 2 headphone outputs with dedicated volume adjustment
  • MIDI in and out

Power Requirements:

12 VDC 2.0 A, positive tip.
Adapter model: PS1225DC


Included Software

FW810s-SteinbergCubase PantheonII FW810s-EzDrummer FW810s-XLIS3

The I-O|82 contains all the necessary tools to transform your computer into a professional 24-bit/96kHz digital recording studio.


  Version Language Size Uploaded
file type icon I-O | 82 Owner's Manual-English
en updated: Nov 2023
  en  2.88 MB Nov 2023
platform icon Lexicon I-O Driver
version 3.3.11, updated: Oct 2016
3.3.11     1.09 MB Oct 2016
platform icon I-O | 82 Driver
version 2.9.77, updated: Feb 2017
2.9.77     1.51 MB Feb 2017
platform icon I-O | 82 Driver
version 2.9.77, updated: Feb 2017
2.9.77     2.53 MB Feb 2017

If any of the links above result in strange characters in your browser, please right-click the file to save it to your computer.


I-O | 82 FAQs

The driver doesn't install on Windows 8 / Windows 10. How can I get it to work?

Currently by default Microsoft has an option that can prevent some of Lexicon's drivers from installing properly. This option can be turned off through Windows Advanced Boot options menu. Lexicon recommends to follow THIS guide using the procedure in option two. For any reason you still have issues feel free to let us know at: Support@Lexiconpro.com
